A - 59
A Appendix
GX-series EtherCAT Slave Unit User’s Manual
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
The meanings of the set values for the Backup Settings are as follows:
3202 hex Backup Setting
Sub-index 0: Number of entries
Range: − Unit: − Default: 08 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port1 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 2: Port2 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 3: Port3 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 4: Port4 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 5: Port5 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 6: Port6 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 7: Port7 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 8: Port8 Backup Setting
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Set value Meaning
00 hex The backup functions are disabled.
01 hex The backup functions are enabled.
