A - 63
A Appendix
GX-series EtherCAT Slave Unit User’s Manual
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
*1 Command is used to clear the IO-Link device backup data that is stored in the IO-Link Master Unit.
The meanings of the set values are as follows:
*2 Result is used to display the cleared status of the IO-Link device backup data that is stored in the IO-Link Master Unit.
The meanings of the values are as follows:
320A hex Message timeout for IO-Link device
Sub-index 0: Number of entries
Range: − Unit: − Default: 02 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Session Timeout
Range: 00 to FF hex Unit: − Default: 03 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
320B hex
*1
Digital Input Collection Setting
Sub-index 0: Number of entries
Range: − Unit: − Default: 08 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port 1 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 2: Port 2 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 3: Port 3 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 4: Port 4 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 5: Port 5 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 6: Port 6 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 7: Port 7 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 8: Port 8 Digital Input Collection Setting
Range: 00 to 01 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Set value Meaning
01 hex Clears the IO-Link backup data.
00 hex Does not clear the IO-Link backup data.
Set value Meaning
0000 hex Backup completed or not executed.
0001 hex Backup failed.
FFFF hex Execution is in progress.
