A Appendix
A - 62
GX-series EtherCAT Slave Unit User’s Manual
Set the filter times for the digital input signals in the Input Filter Settings object.
The meanings of the set values are as follows:
3205 hex Input Filter Setting
Sub-index 0: Number of entries
Range: − Unit: − Default: 08 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port1 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 2: Port2 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 3: Port3 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 4: Port4 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 5: Port5 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 6: Port6 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 7: Port7 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 8: Port8 Input Filter Value Setting
Range: 00 to 0B hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
3209 hex Backup Data Clear Trigger
Sub-index 0: Number of entries
Range: − Unit: − Default: 02 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Command
*1
Range: 00 hex or 01 hex Unit: − Default: 00 hex Attribute: A
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 2: Result
*2
Range: 0000 to FFFF hex Unit: − Default: 0000 hex Attribute: −
Size: 2 bytes (U16) Access: RO PDO map: Not possible
Set value Meaning
00 hex No filter
01 hex 0.25 ms
02 hex 0.5 ms
03 hex 1 ms (default)
04 hex 2 ms
05 hex 4 ms
06 hex 8 ms
07 hex 16 ms
08 hex 32 ms
09 hex 64 ms
0A hex 128 ms
0B hex 256 ms
