3 Functions of NB-Designer
3-76
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
1
Perform the offline test. When LB10 is OFF, the input by the number input component is invalid,
and the icon indicating [Unable-to-Input] is displayed, as shown in the following left graphics.
2
When LB10 is ON, the input by the number input component is valid, and the icon indicating
[Unable-to-Input] isn’t displayed as shown in the following right graphics.
Example of Security Setting
Example: Set LW0 to the address of number input component, check Operator Comfirm, and select
10 s for “wait[s]”.
To Next Page
