Omron NB-series User Manual

3 Functions of NB-Designer
3-126
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
When characters “ABC” are input
(2) Select [Right] in [Alignment] of [Font Property]
When the character “A” is input
When characters “AB” are input
When characters “ABC” are input
Highest Word Word 2 Word 1 Lowest Word (Word 0)
High byte Low byte High byte Low byte High byte Low byte High byte Low byte
20(H) 20(H) 20(H) 20(H) 20(H) 43(H) 42(H) 41(H)
CBA
Highest Word Word 2 Word 1 Lowest Word (Word 0)
High byte Low byte High byte Low byte High byte Low byte High byte Low byte
41(H) 20(H) 20(H) 20(H) 20(H) 20(H) 20(H) 20(H)
A
Highest Word Word 2 Word 1 Lowest Word (Word 0)
High byte Low byte High byte Low byte High byte Low byte High byte Low byte
42(H) 41(H) 20(H) 20(H) 20(H) 20(H) 20(H) 20(H)
BA
Highest Word Word 2 Word 1 Lowest Word (Word 0)
High byte Low byte High byte Low byte High byte Low byte High byte Low byte
43(H) 42(H) 41(H) 20(H) 20(H) 20(H) 20(H) 20(H)
CBA
