Omron NB-series User Manual

3-183
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-6 Parts
3
3-6-24 Note Book
After all the components are placed well, the operation are as follows:
1 Trigger the Text Input component to make the cursor appear, as shown below.
2 Click the English-Chinese Switch once, then the input bar for Chinese input will appear, as
shown below.
3 Several homophones will appear in the Chinese input bar after the PinYin character is input,
and you can use the “PgUp” or “PgDn” button to realize page turning, and trigger the related
Chinese character to complete one Chinese character input process. As shown below, for
example, if “ ” needs to be input, you just need to enter “zhang” through the character
keyboard.
Later, when “ ” is triggered, “ ” will be displayed in the Text Input
component, as shown below.
PinYin Input Window
Please input your name:
PinYin Input Window
Please input your name:
PinYin Input Window
Please input your name:
