3 Functions of NB-Designer
3-244
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
2
Select the [Add] button to add the setting or select the [Modify] button to modify the existing
setting.
Descriptions of Alarm Information Property
Triggered PT Select one PT to specify the Alarm Setting when multiple PTs were registered to the
project.
PLC Address Specifies the bit address of the memory that triggers the read of the alarm.
Property ON When the specified bit address is ON, one piece of alarm information is generated.
OFF When the specified bit address is OFF, one piece of alarm information is generated.
Use Buzzer When the alarm information is triggered, the buzzer will be enabled. The Buzzing
Time can be set with the unit of “second”.
Message Inputs the contents of alarm setting to be displayed. Clicking [Font] can set the Font
and the related attributes.
Use Text Library Determines whether to use the contents logged in the Text Library. For the use of
the Library, refer to [3-8-1 Text Library].
Language When using multi-language Text Library, you can select the language here and click
“Font” to set the font attributes corresponding to text in each kind of language
respectively.
To Next Page
