3 Functions of NB-Designer
3-304
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
Setting Permission Control of Component:
Select the [Conditional Enabling] option in the [Control Setting] tab of “Bit Button Component
Property” and check [Use Permission Control], as shown below.
Setting “Use Permission Control” for the component means only the user having this operation
authority can operate the component restricted by this authority.
Addresses Functions Descriptions
LW9486~LW9501 Input the login user name. 32 characters max.
LW9502~LW9503 Input the password
corresponding to the login user.
Double-word
LW9506~LW9507 Assign the user authority. Double-word, Read/Write component, 32 authority
assignments. LW 9506 to LW 9507 corresponds to
32 authorities (No. 0 to 31) and LW.B corresponds
to each bit in LW 9506 to LW 9507. For example:
LW.B 9506.0 represents the authority of No. 0; and
LW.B 9506.A represents the authority of No. 10.
LW9508~LW9509 Logout time Double-word, Unit: minute
LW9510~LW9511 Add/Delete user confirmed
password.
Double-word
LB9167 Add the user permission. After it is turned ON, the operation is completed
and later it is turned OFF automatically.
LB9168 Delete the user permission. After it is turned ON, the operation is completed
and later it is turned OFF automatically.
LB9169 Modify the password After it is turned ON, the current user password will
be modified, and later it is turned OFF
automatically.
To Next Page
