Omron NB-series User Manual

3-323
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-11 Address of System Memory
3
3-11-1 Local Bit (LB)
9140 Caps Lock When this bit is set to ON, the alphabets will be input in
capital form (read/write).
9141 Turning OFF the current beep When this bit is set to ON, the current beeping is
stopped and the bit turns OFF (read/write).
9142 Trigger the input component of pop-up
screen
When this bit is set to ON, the input component located
on the top of the pop-up screen will be executed
(read/write).
9144 Hide component with communication
failure
When this bit is set to ON, the components with the
communication failure will not be displayed (read/write).
9145 Restart automatically after system
collapse
When this bit is set to ON, the PT will restart
automatically 5 seconds after PT collapse (read/write).
9150 Execute project/recipe import/export
function
When this bit is set to ON, the import/export operation
of project or recipe will be executed (read/write).
9151 Protection bit for project export This bit will be set to OFF after the upload password is
input correctly during the project export; otherwise it will
be set to ON (read/write).
9152 Switch between tree folder and list folder ON is for tree folder and OFF is for list folder
(read/write) respectively.
9154 Inserting and Ejecting USB memory When USB memory is inserted, it will turn ON and it
should be turned OFF before removal to ensure the
safe removal of USB memory (read/write).
9161 Align-left display on keyboard When this bit is set to ON, the display component
(LW9060) on the keyboard will be displayed in left-
aligned way during the input (read/write).
9162 Vector font optimized display When this bit is set to ON, the vector font edge display
effect will be optimized (read/write).
9163 Screen display state When this bit is set to ON, the screen will be displayed
vertically reversed. This bit is applicable when the
display is horizontally oriented (read/write).
9165 User login When this bit is set to ON, the user login operation is
performed, and later the bit will be set to OFF
automatically (write).
9166 User logout When this bit is set to ON, the user logoff operation will
be performed, and later the bit will be set to OFF
automatically (write).
9167 Add user When this bit is set to ON, the user addition operation
will be performed, and later the bit will be set to OFF
automatically (write).
9168 Delete user When this bit is set to ON, the user deletion operation
will be performed, and later the bit will be set to OFF
automatically (write).
9175 Web interface When the bit is ON, the Web interface is valid.
(read/write)
9251 Printing event manually (not currently
support)
When it is set to ON, forced printing of triggered events
up to now will be executed (read/write).
Addresses Descriptions Comments
