3-341
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-12 Recipe Data
3
3-12-3 Upload/Download of Recipe Data between PT and PLC
7
Place another keyboard in the screen, and add some texts for decoration, then the project is
thoroughly completed.
After Save, Compile operations, perform the offline test for the project.
Input the 10 groups of recipe data into the recipe memory one by one, then switch to Group 8
of recipe data to change the name to “KKKKKKKK”, recipe data to “1234”, then you will see the
data in 4X100 and 4X104 will become “KKKKKKKK” and “1234” respectively after the
Download button is pressed, as shown below:
