Omron NB-series User Manual

3-363
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-16 Other Functions
3
“Back Space” and “Clear” functions of Function Key is prior to the input Pinyin characters, i.e. when
the Pinyin characters are input currently, the object operated by the “Back Space” and “Clear”
function is the Pinyin characters instead of the other characters in the text input area.
Note When the font size is 8, 24, 48, 72 or 96, the Pinyin input method is invalid.
8 LSB Type
LSB type is applicable to the Command Button component, Word Lamp component, and Word
Neon Lamp component. If the Bit Button component is operated, the text string to display in
neon lamp and others can be controlled.
LSB is the acronym of Least Significant Bit. This encoding type first converts the data in the
buffer to binary data, and then determines the current state of the component based on the
number of consecutive “0” at the least significant bits of the binary data.
[Example] Take an example of the data with word address to be displayed:
9 Disconnected Host can be Masked of the Station No.
The disconnected Host can be masked with the communication error. If the settings are valid,
all the “PLC No Response” for the device behind can be masked.
10 Data Log, XY Graph and Oscillograph
Data Log/XY Graph/Oscillograph components have extended Properties, as shown below:
(a) Border, Grid and Background Color etc.
(b) Display Type of sampling point.
Hexadecimal Decimal Binary
Number of
consecutive “0” at
least significant bits
State Number
0000 0 0000 0000 0000 0000 16 16
0001 1 0000 0000 0000 0001 0 0
0002 2 0000 0000 0000 0010 1 1
0003 3 0000 0000 0000 0011 0 0
0004 4 0000 0000 0000 0100 2 2
0005 5 0000 0000 0000 0101 0 0
0006 6 0000 0000 0000 0110 1 1
0007 7 0000 0000 0000 0111 0 0
0008 8 0000 0000 0000 1000 3 3
…… … … …
0010 16 0000 0000 0001 0000 4 4
0020 32 0000 0000 0010 0000 5 5
0040 64 0000 0000 0100 0000 6 6
0080 128 0000 0000 1000 0000 7 7
0100 256 0000 0001 0000 0000 8 8
0200 512 0000 0010 0000 0000 9 9
0400 1024 0000 0100 0000 0000 10 10
0800 2048 0000 1000 0000 0000 11 11
1000 4096 0001 0000 0000 0000 12 12
2000 8192 0010 0000 0000 0000 13 13
4000 16384 0100 0000 0000 0000 14 14
8000 32768 1000 0000 0000 0000 15 15
…… … … …
