3-375
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-16 Other Functions
3
The successful import of graphics is as shown below:
(3) After saving the project, quit from the graphic edit window and enter the edit window.
(4) Place one Bitmap component, and check [Use Original Size].
(5) When the offline simulation is performed, and the effect is as shown below:
