3-5
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-1 User Screen
3
Toolbar
1
Common Toolbar
Includes some basic tools such as “New”, “Open”, “Cut” and “Copy” etc.
2
Draw Toolbar
Each image of figure drawing is displayed in icons. The available drawing tools include Line,
Rectangle, Ellipse, Sector, Polygon, Text etc.
3
Screen Toolbar
Performs Up/Down operation of the screen.
4
Component Edit Toolbar
Adjusts the position of the component (i.e. top-alignment, bottom-alignment, left-alignment,
right-alignment etc), the size, cascading, combination and flip methods.
5
Line Width Toolbar
Adjusts the width of the line in the figure.
6
Line Style Toolbar
Add or delete the arrow head, replace solid line with broken line in the figures.
7
System Toolbar
Performs the compilation, downloading and test of the project.
8
Database Toolbar
Includes text library, alarm information, Variable Table, PLC control and event information.
9
Code Edit Toolbar
The icon to edit macro is displayed.
10
Pattern Toolbar
Select the filling-style of screen background or the closed space such as rectangle, ellipse,
sector etc.
11
Label Component Edit Toolbar
Performs the alignments of the label such as label aligning to the left-border/right-border/top-
border or bottom-border of the component, label locating in the vertical center or horizontal
center of the component.
12
State Switch Toolbar
Simulates the switching of the various states of each component in the current screen and
languages.
13
Font Toolbar
Sets dot matrix/vector/graphics mode, font and font size of various kinds of texts displayed in
the screen.
