Omron NB-series User Manual

Appendices
A-12
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
 Omron CP1H/L/E
 OMRON CJ/CS/NJ Series Ethernet (UDP Slave)
Device Bit Address Word Address Format
Work Area W_bit 0.00-511.15 ------ DDD.DD
Hold Area H_bit 0.00-1535.15 ------ DDDD.DD
Data Area D_bit 0.00-32767.15 ------ DDDDD.DD
Counter
(Completion Flag)
C_Flag 0.00-4095.00 ------ DDDD.DD
Timer
(Completion Flag)
T_Flag 0.00-4095.00 ------ DDDD.DD
Auxiliary A_bit 0.00-959.15 ------ DDD.DD
CIO Area CIO_bit 0.00-6143.15 ------ DDDD.DD
Work Area ------ W 0-511 DDD
Hold Area ------ H 0-1535 DDDD
Data Area ------ D 0-32767 DDDDD
Counter Area ------ C 0-4095 DDDD
Timer Area ------ T 0-4095 DDDD
Auxiliary Area ------ A 0-959 DDD
CIO Area ------ CIO 0-6143 DDDD
Device Bit Address Word Address Format
CIO Area CIO_bit 0000.00-6143.15 ------ DDDD.DD
Work Area W_bit 000.00-511.15 ------ DDD.DD
Auxiliary Area A_bit 000.00-11535.15 ------ DDDDD.DD
Holding Area H_bit 000.00-1535.15 ------ DDDD.DD
Timer
(Completion Flag)
T_FLAG 0000-4095 ------ DDDD
Counter
(Completion Flag)
C_FLAG 0000-4095 ------ DDDD
Data Memory D_bit 00000.00-32767.15 ------ DDDDD.DD
Extension Data
Memory Area
(E0-E18)
E0_bit 0.00-32767.15
…
E18_bit 0.00-32767.15
------ DDDDD.DD
Counter Release
Forced Status Area
C_RELEASE_STATUS
0000-4095
------ DDDD
Timer Release Forced
Status Area
T_RELEASE_STATUS
0000-4095
------ DDDD
Holding Release
Forced Status Area
H_RELEASE_STATUS
0.00-511.15
------ DDD.DD
Work Release Forced
Status Area
W_RELEASE_STATUS
0.00-511.15
------ DDD.DD
CIO Release Forced
Status Area
CIO_RELEASE_STATUS
0.00-6143.15
------ DDDD.DD
Holding Set/Reset
Forced Release Area
H_FORCED_RELEASE
0.00-511.15
------ DDD.DD
Holding Forced
Set/Reset Area
H_FORCED 0.00-511.15 ------ DDD.DD
Work Set/Reset
Forced Release Area
W_FORCED_RELEASE
0.00-511.15
------ DDD.DD
Work Forced
Set/Reset Area
W_FORCED 0.00-511.15 ------ DDD.DD
