A-3 List of memories supported by OMRON PLC
App
CIO Set/Reset Forced
Release Area
CIO_FORCED_RELEASE
0000.00-6143.15
------ DDDD.DD
CIO Forced Set/Reset
Area
CIO_FORCED
0000.00-6143.15
------ DDDD.DD
Task Flag Area TK_FLAG 0-127 ------ DDD
Counter Set/Reset
Forced Release Area
C_FORCED_RELASE
0000-4095
------ DDDD
Counter Forced
Set/Reset Area
C_FORCED
0000-4095
------ DDDD
Timer Set/Reset
Forced Release Area
T_FORCED_RELASE
0000-4095
------ DDDD
Timer Forced
Set/Reset Area
T_FORCED
0000-4095
------ DDDD
Extension Data
Memory
(E0-E18)
------ E0 0-32767
…
E18 0-32767
DDDDD
EM Area ------ EM 0-32767 DDDDD
CIO Area ------ CIO 0000-6143 DDDD
Work Area ------ W 000-511 DDD
Auxiliary Area ------ A 000-11535 DDDDD
Holding Area ------ H 000-1535 DDDD
Timer Area ------ T 0000-4095 DDDD
Counter Area ------ C 0000-4095 DDDD
Data Memory ------ D 00000-32767 DDDDD
Index memory Area ------ IR 00-15 DD
Data memory Area ------ DR 00-15 DD
Task Flag Area ------ TK 00-127 DDD
Device Bit Address Word Address Format
