Appendices
A-14
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
OMRON CP Series Ethernet (UDP Slave)
Device Bit Address Word Address Format
CIO Area CIO_bit 0000.00-6143.15 ------ DDDD.DD
Work Area W_bit 000.00-511.15 ------ DDD.DD
Auxiliary Area A_bit 000.00-959.15 ------ DDD.DD
Holding Area H_bit 000.00-1535.15 ------ DDDD.DD
Timer
(Completion Flag)
T_FLAG 0000-4095 ------ DDDD
Counter
(Completion Flag)
C_FLAG 0000-4095 ------ DDDD
Data Memory D_bit 00000.00-32767.15 ------ DDDDD.DD
Counter Release
Forced Status Area
C_RELEASE_STATUS
0000-4095
------ DDDD
Timer Release Forced
Status Area
T_RELEASE_STATUS
0000-4095
------ DDDD
Holding Release
Forced Status Area
H_RELEASE_STATUS
0.00-511.15
------ DDD.DD
Work Release Forced
Status Area
W_RELEASE_STATUS
0.00-511.15
------ DDD.DD
CIO Release Forced
Status Area
CIO_RELEASE_STATUS
0.00-6143.15
------ DDDD.DD
Holding Set/Reset
Forced Release Area
H_FORCED_RELEASE
0.00-511.15
------ DDD.DD
Holding Forced
Set/Reset Area
H_FORCED
0.00-511.15
------ DDD.DD
Work Set/Reset
Forced Release Area
W_FORCED_RELEASE
0.00-511.15
------ DDD.DD
Work Forced
Set/Reset Area
W_FORCED
0.00-511.15
------ DDD.DD
CIO Set/Reset Forced
Release Area
CIO_FORCED_RELEASE
0000.00-6143.15
------ DDDD.DD
CIO Forced Set/Reset
Area
CIO_FORCED
0000.00-6143.15
------ DDDD.DD
Task Flag Area TK_FLAG 0-31 ------ DD
Counter Set/Reset
Forced Release Area
C_FORCED_RELEASE
0000-4095
------ DDDD
Counter Forced
Set/Reset Area
C_FORCED 0000-4095 ------ DDDD
Timer Set/Reset
Forced Release Area
T_FORCED_RELEASE
0000-4095
------ DDDD
Timer Forced
Set/Reset Area
T_FORCED
0000-4095
------ DDDD
CIO Area ------ CIO 0000-6143 DDDD
Work Area ------ W 000-511 DDD
Auxiliary Area ------ A 000-959 DDD
Holding Area ------ H 000-1535 DDDD
Timer Area ------ T 0000-4095 DDDD
Counter Area ------ C 0000-4095 DDDD
Data Memory ------ D 00000-32767 DDDDD
Index memory Area ------ IR 00-15 DD
Data memory Area ------ DR 00-15 DD
Task Flag Area ------ TK 00-31 DD
