247
Specifications
Appendix A
[For RS-232C] (NT20S-ST128)
Item
Specification
Communication standard
EIA RS-232C
Communication settings
Start-stop synchronization
Baud rate:
2400/4800/9600/19200
(bps)
Data length:
7, 8 bits
Stop bit:
1, 2 bits
Parity:
Even/Odd/None
Flow control:
RS/CS control
XON/XOFF control
None
Connector
9-pin D-SUB female
Number of units connected
1-to-1
Transmission distance
Max. 15 m
