Item
Specifications
NX701-£££
£
NX102-£££
£
NX1P2-££
££££
NJ501-££££
NJ301-££££
NJ101-£££
£
Unit version
1.10 or later
Unit version
1.30 or later
Unit version
1.13 or later
Unit version
1.00 to 1.02
Unit version
1.03 or later
Unit version
1.10 or later
CIP message
service:
Explicit
messages
*9
Class 3 (number of
connections)
Connections:
128 per port
(total of 256
with two
ports) (clients
plus server)
Connections:
32 per port
(total of 64
with two
ports) (clients
plus server)
Number of connections: 32 (clients plus servers)
UCMM (uncon-
nected)
Number of clients that can communicate at one time: 32 max.
Number of servers that can communicate at one time: 32 max.
CIP routing
*10
Supported
CIP routing is supported for the following remote Units:
NX701-££££, NX102-££££, NX1P2-££££,
NJ501-££££, NJ301-££££, NJ101-££££,
CS1W
-EIP21, CJ1W-EIP21,
CJ2H-CPU££-EIP, and CJ2M-CPU3£.
Using a combination of any Units above, communication can be extended up to a maximum of
8 levels.
SNMP
Agents SNMPv1 or SNMPv2c
MIB MIB-II
EtherNet/IP conformance test
Conforms to
CT1
1
Conforms to
CT14
Conforms to
CT13
NJ501: Conforms to CT12
NJ301: Conforms to CT14
Conforms to
CT14
Ethernet interface
10Base-T,
100Base-TX,
or 1000Base-
T
Auto negotia-
tion or fixed
settings
10Base-T or 100Base-TX
Auto negotiation or fixed settings
*1. If tag data links are being used, use 100Base-TX or 1000Base-T.
*2. Here, pps means “packets per second” and indicates the number of packets that can be processed in one second.
*3. If the two built-in EtherNet/IP ports are used simultaneously, the maximum communications data size for two ports in total will be
reached.
*4. An NX102 CPU Unit with unit version 1.31 or later is required to use the CIP Safety routing.
*5. To use a data size of 505 bytes or larger, the system must support a large forward open (an optional CIP specification). The CS, CJ,
NJ, and NX-series Units support a large forward open, but before connecting to nodes of other companies, confirm that the devices
also support it.
*6. When tag sets that exceed total of 40 are set, a Number of Tag Sets for Tag Data Links Exceeded (840E0000 hex) event occurs.
*7. If the parameters of the built-in EtherNet/IP port are changed, the port is restarted. When other nodes are in communications with the
af
fected node, the communications will temporarily time out and automatically recover after the restart.
*8. Because the built-in EtherNet/IP port is equipped with an IGMP client (version 2), unnecessary multicast packets can be filtered out by
an Ethernet switch that supports IGMP snooping.
*9. The built-in EtherNet/IP port uses the TCP/UDP port numbers shown in the following table.
Do not set the same port number for more than one TCP/UDP service.
Service Protocol Port number Remarks
EIP data links UDP 2222 Fixed values
Used by system UDP 2223, 2224
TCP 9610
CIP messages TCP 44818
FTP client data transfer port TCP 20
DNS client TCP/UDP 53
BOOTP client UDP 68
HTTP server TCP 80
1 Introduction
1-10
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
