Method 1: Disabling Windows Firewall Settings
Precautions for Correct Use
The main function of the firewall is to prevent unwanted access from external sources (e.g., the
Internet).
The changes that are made with the following procedures are to allow the Sysmac Studio and
the NJ/NX-series Controller to connect. If your computer is on an inhouse network, make sure
that security will not be jeopardized before you change the settings.

Windows XP
1 Open the Control Panel from the Windows Start Menu and then select Windows Firewall
icon.
The Windows Firewall Dialog Box is displayed.
2 Click on the Exceptions
tab and select Sysmac Studio in the Programs and Services list.
Appendices
A-36
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
