Omron NX1P2 series Hardware User Manual

A-2-4
Option Boards
NX1W-CIF01
35.9
13.5
35.9
0.7
0.7
Unit: [mm]
8.8 0.6
3.5
NX1W-CIF11/-CIF12
35.9
13.5
35.9
0.7
0.7
3.5
Unit: [mm]
5.6
0.6
NX1W-ADB21/ -DAB21V/ -MAB221
36.4
36.4
0.45
0.45
NX1W-ADB21 NX1W-DAB21V NX1W-MAB221
28.2
Unit: [mm]
5.4
0.6
Appendices
A-5
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
A-2 Dimensions
A
A-2-4 Option Boards

Omron NX1P2 series Specifications

General

Model	NX1P2 Series
Manufacturer	Omron
Type	Controller
CPU Units	1
Program Capacity	5 MB
Data Memory Capacity	128 KB
Ethernet Ports	1
Serial Ports	1
Built-in EtherNet/IP Port	Yes
Built-in EtherCAT Port	Yes
Built-in USB Port	Yes
SD Memory Card Slot	Yes
USB Port	1
Power Supply Voltage	24 VDC
Programming Language	Ladder, Structured Text, Function Block Diagram
Communication Protocols	EtherNet/IP, EtherCAT, Serial (RS-232C)
