5-3-10
Battery Installation
Battery to Use
Use the Battery CJ1W-BAT01 which is sold separately.
Precautions for Correct Use
Be sure to install a Battery within two years of the production date shown on the Battery label.
CJ1W-BAT01
18-03
Manufactured in March 2018.
Production Date
Battery Installation Procedure
Use the following procedure to install the Battery.
Precautions for Safe Use
We recommend mounting or replacing the Battery with the power turned OFF to prevent the CPU
Unit’s sensitive internal components from being damaged by static electricity and to prevent mal-
functions. The Battery can be mounted or replaced without turning OFF the power supply
. To do
so, always touch a grounded piece of metal to discharge static electricity from your body before
starting the procedure.
If the Low Battery Voltage error occurs after you mount the Battery, connect the Sysmac Studio
and clear the error.
Additional Information
UL standards require that batteries be installed or replaced by experienced technicians. Always
place an experienced technician in charge of the procedure.
1 Turn OFF the power supply to the Controller.
If the CPU Unit has not been ON, turn it ON for at least five minutes and then turn it OFF.
2 Using a flat-blade screwdriver
, remove the battery cover on the lower left corner of the CPU
Unit.
5 Installation and Wiring
5-34
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
To Next Page
