3) Wiring I/O
• Wiring the built-in I/O
• Wiring I/O for NX Units
• Wiring an Option Board
5-4-9 Wiring the built-in I/O
on page 5-65
Manuals for the specific NX
Units
5-4-10 W
iring the NX1W-
CIF01 Serial Communica-
tions Option Board on page
5-69
5-4-12 Wiring the Analog I/O
Option Board on page 5-77
• Wiring I/O to EtherCAT slaves
Operation manuals for the
EtherCAT slaves
5-4
Wiring on page 5-43
4) Connecting the
Computer That Runs
the Sysmac Studio
• Connecting the built-in EtherNet/IP port
Sysmac Studio Version 1
Operation Manual (Cat. No.
W504)
STEP5. Checking Operation and Starting Operation on the Actual System
Step Description Sysmac Studio
Operations
Reference
1) Online Connection
to Sysmac Studio and
Project Download
Turn ON the power supply to the Control-
ler and place the Sysmac Studio online.
Then, download the project.
*1
Perform this step before you create the
slave configuration or NX Unit configura-
tion from the mounted Units in step 2-1.
Controller −
Communications
Setup −
Controller −
Synchronization
NJ/NX-series CPU Unit
Software User’s Manual
(Cat. No. W501)
2) Clock Data Setting Set the clock data with the clock function
when the battery is mounted.
Controller −
Controller Clock
NJ/NX-series CPU Unit
Software User’
s Manual
(Cat. No. W501)
3) Operation Check on
Controller
1. Check the wiring by using forced re-
freshing of real I/O from the I/O Map
or Watch T
ab Page.
2. For motion control, use the MC Test
Run operations in PROGRAM mode
to check the wiring. Then check the
motor rotation directions for jogging,
travel distances for relative position-
ing (e.g., for electronic gear settings),
and homing operation.
3. Change the Controller to RUN mode
and check the operation of the user
program.
--- NJ/NX-series CPU Unit
Software User’s Manual
(Cat. No. W501)
1 Introduction to NX-series Controllers
1-19
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
1-3 Overall Operating Procedure
for the CPU Unit
1
1-3-2 Procedure Details
