3-78
3-6 Parameter Unit Specifications
3
Specifications
3-6 Parameter Unit Specifications
The Parameter Unit is required for parameter setting and monitoring for the Servo Drive.
R88A-PR02G Hand-held Parameter Unit
îš„ General Specifications
îš„ Performance Specifications
Item Specifications
Operating ambient temperature
Operating ambient humidity
0 to 55°C
90% RH max. (with no condensation)
Storage ambient temperature
Storage ambient humidity
−20 to 80°C
90% RH max. (with no condensation)
Operating and storage
atmosphere
No corrosive gases
Vibration resistance 5.9 m/s
2
max.
Item Specifications
Type Hand-held
Cable length 1.5 m
Connectors Mini DIN 8P MD connector
Display 7-segment LED
External dimensions 62 (W) × 114 (H) × 15 (D) mm
Weight Approx. 0.1 kg (including cable)
Communications
specifications
Standard RS-232
Communications method Asynchronous (ASYNC)
Baud rate 9,600 bps
Start bits 1 bit
Data 8 bits
Parity None
Stop bits 1 bit
To Next Page
