3-1
3-1 Servo Drive Specifications
3
Specifications
3Specifications
3-1 Servo Drive Specifications
Select the Servo Drive matching the Servomotor to be used.
(For details, refer to Servo Drive-Servomotor Combinations on page 2-2.)
General Specifications
Note 1. The above items reflect individual evaluation testing. The results may differ under compound
conditions.
Note 2. Depending on the operating conditions, some Servo Drive parts will require maintenance.
Refer to Servo Drive Service Life on page 8-18 in the User’s Manual for details.
Note 3. The service life of the Servo Drive is 50,000 hours at an average ambient temperature of
40°C at 80% of the rated torque (excluding axial-flow fan).
Item Specifications
Ambient operating temperature
Ambient operating humidity
0 to 55°C, 90% RH max. (with no condensation)
Ambient storage temperature
Ambient storage humidity
−20 to 65°C, 90% RH max. (with no condensation)
Storage and operating
atmosphere
No corrosive gasses, no dust, no iron dust, no exposure to moisture
or cutting oil
Vibration resistance 10 to 60 Hz; acceleration: 5.9 m/s
2
(0.6 G) max.
Impact resistance Acceleration of 19.6 m/s
2
max. 3 times each in X, Y, and Z directions.
Insulation resistance
Between power supply/power line terminals and frame ground:
0.5 MΩ. min. (at 500 VDC)
Dielectric strength
Between power supply/power line terminals and frame ground:
1,500 VAC for 1 min at 50/60 Hz
Between each control signal and frame ground: 500 VAC for 1 min
Altitude 1,000 m above sea level max. (860 hp min.)
Protective structure Built into panel (IP10).
Interna-
tional
stan-
dards
EC
Direc-
tives
EMC
Directive
EN 55011 class A group 1
EN 61000-6-2
Low
Voltage
Directive
EN 50178
UL standards UL 508C
cUL standards cUL C22.2 No.14
WARNING
Never perform withstand-voltage or other megameter tests on the Servo
Drive.
