Omron SMARTSTEP 2 SERIES User Manual

2-12
2-1 Standard Models
2
Standard Models and Dimensions
 Connector-Terminal Block Conversion Units
 External Regeneration Resistors
 Reactors
 DIN Rail Mounting Unit
Specifications Model
M3 screws type XW2B-34G4
M3.5 screws type XW2B-34G5
M3 screws type XW2D-34G6
Specifications Model
Regeneration capacity: 70 W, 47 Ω R88A-RR22047S
Regeneration capacity: 20 W, 100 Ω R88A-RR080100S
Regeneration capacity: 20 W, 50 Ω R88A-RR08050S
Specifications Applicable Servo Drive Model
Single-phase 100 V
R7D-BPA5L 3G3AX-DL2002
R7D-BP01L 3G3AX-DL2004
R7D-BP02L 3G3AX-DL2007
Single-phase 200 V
R7D-BP01H 3G3AX-DL2004
R7D-BP02HH 3G3AX-DL2004
R7D-BP04H 3G3AX-DL2007
Three-phase 200 V
R7D-BP01H 3G3AX-AL2025
R7D-BP02H 3G3AX-AL2025
R7D-BP04H 3G3AX-AL2025
Specifications Model
DIN Rail Mounting Unit R7A-DIN01B
