2-1 Standard Models

Standard Models and Dimensions

 Servo Relay Unit Cables for Position Control Units

 Control Cables (for CN1)

Specifications Model

Position Control

Unit Cables

For CJ1W-NC133

0.5 m XW2Z-050J-A18

1 m XW2Z-100J-A18

For CJ1W-NC233/-NC433

0.5 m XW2Z-050J-A19

1 m XW2Z-100J-A19

For CS1W-NC133

0.5 m XW2Z-050J-A10

1 m XW2Z-100J-A10

For CS1W-NC233/-NC433

0.5 m XW2Z-050J-A11

1 m XW2Z-100J-A11

For CJ1W-NC113

0.5 m XW2Z-050J-A14

1 m XW2Z-100J-A14

For CJ1W-NC213/-NC413

0.5 m XW2Z-050J-A15

1 m XW2Z-100J-A15

For CS1W-NC113

For C200HW-NC113

0.5 m XW2Z-050J-A6

1 m XW2Z-100J-A6

For CS1W-NC213/-NC413

For C200HW-NC213/-NC413

0.5 m XW2Z-050J-A7

1 m XW2Z-100J-A7

For CJ1M-CPU21

For CJ1M-CPU22

For CJ1M-CPU23

0.5 m XW2Z-050J-A33

1 m XW2Z-100J-A33

For FQM1-MMP22

General-purpose

I/O Cables

0.5 m XW2Z-050J-A28

1 m XW2Z-100J-A28

2 m XW2Z-200J-A28

Special I/O Cables

0.5 m XW2Z-050J-A30

1 m XW2Z-100J-A30

2 m XW2Z-200J-A30

For CQM1H-PLB21

For CQM1-CPU43-V1

0.5 m XW2Z-050J-A3

1 m XW2Z-100J-A3

Specifications Model

Connector-Terminal Block Cables 1 m XW2Z-100J-B28

2 m XW2Z-200J-B28

General-purpose Control Cables 1 m R7A-CPB001S

2 m R7A-CPB002S
