Omron SMARTSTEP 2 SERIES User Manual

5-15
5-8 Torque Limit
5
Operating Functions
5-8 Torque Limit
 This function limits the output torque of the Servomotor.
 This function is effective in the following cases:
Pressing a moving part of a machine (such as a bending machine) against a workpiece with a
constant force.
Protecting the Servomotor and mechanical system from excessive force or torque.
 The Warning Output Selection (Pn09) can be set to output an alarm to the Warning Output
(WARN) when the torque limit function is enabled.
 Two torque limits can be set and you can switch between them. To switch the torque limit setting,
enable the Torque Limit Switch Input (TLSEL) in the Zero Speed Designation/Torque Limit Switch
(Pn06).
Parameters Requiring Setting
*1. Values exceeding the default setting cannot be set. The default setting depends on the combination of the
Servomotor and Servo Drive.
*2. The Overspeed Detection Level Setting (Pn70) will function only when torque limit switching function is enabled.
Related Parameters
The following parameters must be set to use torque limit switching function.
*1. Values exceeding the default setting cannot be set. The default setting depends on the combination of Servomotor
and Servo Drive.
*2. The No. 2 Overspeed Detection Level Setting (Pn73) will function only when torque limit switching function is
enabled.
Parameter
No.
Parameter name Explanation Reference
Pn5E Torque Limit
*1
Set the torque limit as a percentage of the maximum torque of the
Servomotor.
Page 5-54
Pn63
Deviation Counter
Overflow Level
Set the alarm detection level for deviation counter overflow.
Page 5-56
Pn70
Overspeed
Detection Level
Setting
*2
An overspeed alarm will occur if the Servomotor rotation speed
exceeds the setting of this parameter. Page 5-60
Parameter
No.
Parameter name Explanation Reference
Pn71 No. 2 Torque Limit
*1
These parameters are set when using the No. 2 torque limit.
These parameters function in the same way as the parameters
described above.
Page 5-60
Pn72
No. 2 Deviation
Counter Overflow
Level
Pn73
No. 2 Overspeed
Detection Level
Setting
*2
