Omron SMARTSTEP 2 SERIES User Manual

2-3
2-1 Standard Models
2
Standard Models and Dimensions
 Single-phase 200-VAC Combinations
3,000-r/min Servomotors
3,000-r/min Flat Servomotors
 Three-phase 200-VAC Combinations
3,000-r/min Servomotors
3,000-r/min Flat Servomotors
Rated
output
Servo Drive Servomotor
Pulse-string input Without brake With brake
50 W
R7D-BP01H
R88M-G05030H-@ R88M-G05030H-B@
100 W R88M-G10030H-@ R88M-G10030H-B@
200 W R7D-BP02HH R88M-G20030H-@ R88M-G20030H-B@
400 W R7D-BP04H R88M-G40030H-@ R88M-G40030H-B@
Rated
output
Servo Drive Servomotor
Pulse-string input Without brake With brake
100 W R7D-BP01H R88M-GP10030H-@ R88M-GP10030H-B@
200 W R7D-BP02HH R88M-GP20030H-@ R88M-GP20030H-B@
400 W R7D-BP04H R88M-GP40030H-@ R88M-GP40030H-B@
Rated
output
Servo Drive Servomotor
Pulse-string input Without brake With brake
50 W
R7D-BP01H
R88M-G05030H-@ R88M-G05030H-B@
100 W R88M-G10030H-@ R88M-G10030H-B@
200 W R7D-BP02H R88M-G20030H-@ R88M-G20030H-B@
400 W R7D-BP04H R88M-G40030H-@ R88M-G40030H-B@
Rated
output
Servo Drive Servomotor
Pulse-string input Without brake With brake
100 W R7D-BP01H R88M-GP10030H-@ R88M-GP10030H-B@
200 W R7D-BP02H R88M-GP20030H-@ R88M-GP20030H-B@
400 W R7D-BP04H R88M-GP40030H-@ R88M-GP40030H-B@
