D-100 Display Module BACnet Installation and Operation Guide 04/12 - 0635-2 Page 7
1.4.2 BACnet/IP
BACnet/IP, Base 10T output connections are made as shown. Requires Base 10T cable and
RJ45 connector.
!
CAUTION
Only qualied service personnel should make connections between the D-100 Flow Display and the
user’s external equipment. ONICON assumes no responsibility for damage caused to the external
equipment as a result of an improper installation.
