Connections
Speaker layout
ZONE 2
Main Room
A
B
C
D
A
B
D
A SPEAKER A
Speakers to be connected to the SPEAKERS A terminals. Install in the main
room (where this unit is located).
B SPEAKER B
You can connect another speaker system to this unit. Connect these speakers to
the SPEAKERS B terminals.
C Powered Subwoofer
( →p21)
D ZONE 2 Speakers
The speaker system set up in a separate room (ZONE 2). This enables you to
play the same source in the main room and the separate at the same time, or
to play separate sources. Note that to use ZONE 2 Speakers you will require a
→p28)
Connecting speakers ( →p20)
