102
Appendix
General Specications
Amplier Section North American and Japanese models European, Middle East, Australian and Asian models
Rated Output Power *
(North American models)
With 8 ohm loads, both channels driven, from 20Hz-
20kHz; rated 110 watts per channel minimum RMS
power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output.
(Japanese models)
2 ch × 110 W at 8ohms, 20-20,000Hz, 2ch driven of
0.08% THD (JEITA)
2 ch × 150 W at 6 ohms, 1 kHz, 2 ch driven of 0.7%
THD (JEITA)
2 ch × 140 W at 4 or 6 ohms, 1 kHz, 2 ch driven of 1% THD
2 ch × 120 W at 8 ohms, 1 kHz, 2 ch driven of 1% THD
(North American models)
210 W at 6 ohms, 1 kHz, 2 ch driven of 10% THD
(Japanese models)
2 ch × 190 W at 6 ohms, 1 kHz, 2 ch driven of 10%
THD
2 ch × 170 W at 6 ohms, 1 kHz, 2 ch driven of 10% THD
(JEITA)
0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance
Rated RCA Output Level and Impedance
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%), 7 mV (MC 1 kHz 0.5%)
Frequency Response
Tone Control Characteristics ±10 dB, 100 Hz (Bass), ±10 dB, 10 kHz (Treble)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT),
76 dB (IHF-A, PHONO MM 5mV IN, SP OUT),
60 dB (IHF-A, PHONO MC 0.5mV IN, SP OUT)
Supported impedance of Speakers
