Connections
Connecting the Power Cord
Connect the power cord after all the connections are completed.
• This model includes a removable power cord. Be sure to connect the power

cord.
Note
Japanese models
• Match the power polarity to improve sound quality. Put the side of the power
plug included with this unit with the "N" mark into the side of the outlet with
the longer slot. If both slots are the same length, then you can plug it in either
side.
a Power cord
SPEAKERS
R L
A
LR
B
HDMI IN
ETHERNET USB
HDCP 2.3
PC GAME
5V/1A
SUB-
WOOFER
TUNER
AC INLET
a
