Connections
Connecting Antennas (North American and European models)
Connect the antenna to this unit, and set up the antenna at the best position for
listening while receiving radio signals.
 North American models
SPEAKERS
R L
A
LR
B
FM
75Ω
PRE/LINE OUT PRE OUT
ZONE 2 MAIN
SUB-
WOOFER
AM
TUNER
L
R
L
R
A B
• Attach the indoor FM antenna to the wall using push pins or adhesive tape.
 European models
SPEAKERS
R L
A
LR
B
PRE/LINE OUT PRE OUT
ZONE 2 MAIN
SUB-
WOOFER
TUNER
L
R
L
R
DAB /
FM
c
DAB
a AM loop antenna, b Indoor FM antenna c DAB/FM antenna
