Front Panel≫ Rear Panel≫ Remote≫
1. BLUETOOTH antenna is built in.
2. HDMI OUT jack: Transmit video signals and audio signals with an HDMI cable
connected to a TV.
3. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable
connected to an AV component.
4. POWER OUT jack: The power (5 V/1 A) can be supplied to a streaming media
player, etc. using a USB cable. ( p26)
5. DIGITAL IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio
signals with a digital optical cable or digital coaxial cable.
6. Power cord
7. TUNER AM/FM antenna terminal: Connect the supplied antennas.
8. VIDEO IN jacks: Input AV component video signals with an analog video cable.
9. MONITOR OUT jack: Transmit video signals with an analog video cable
connected to a TV.
• This connection is required to output video signals input from the VIDEO IN
jack to the TV using the analog video cable.
10. AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
11. SUBWOOFER jacks: Connect a powered subwoofer with a subwoofer cable.
Up to two powered subwoofers can be connected. The same signal is output
from each SUBWOOFER jack.
12. SPEAKERS terminals: Connect speakers with speaker cables. (FRONT
terminals for North American models support banana plugs.)
