Attachment
T
CP (x, y
, z) [mm]
Standard
(0
, 0
, 100)
Pipe + Cup
(-17
, 17
, 150)
Adaptor + Cups
(0
, 0
, 110)
Adaptor + Pipe + Cup
(0
, 0
, 160)
For customization
(0
, 0
, 75)
SW INST
ALLATION
59
58
60
