Chapter 5: Firewall, Failover and Out of Band

110 Console Server & RIM Gateway User Manual

5.8 Firewall & Forwarding

Opengear console servers and cellular routers with Version 3.3 firmware (and beyond) have basic routing, NAT (Network

Address Translation), packet filtering and port forwarding support on all network interfaces.
