User Manual
Advanced Console Server & RIM Gateway User Manual 159
7.3.3 Perform RPC Action
Click on Perform RPC Action as the Add Trigger Action. Enter a unique Action Name and set the Action
Delay Time
Select a power Outlet and specify the Action to be performed (power On, OFF or Cycle)
Click Save New Action
7.3.4 Run Custom Script
Click on Run Custom Script as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
Create a script file to execute when this action is triggered and enter the Script Executable file name e.g.
/etc/config/action.sh
Set the Script Timeout (i.e. the maximum run-time for the script). Leave as 0 for unlimited.
Enter any Arguments that are to be passed to the script and click Save New Action
7.3.5 Send SNMP Trap
Click on Send SNMP Trap as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
Note: The SNMP Trap actions are valid for Serial, Environmental, UPS and Cellular data triggers only
7.3.6 Send Nagios Event
Click on Send Nagios Event as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
Edit the Nagios Event Message text to display on the Nagios status screen for the service
Specify the Nagios Event State (OK, Warning, Critical or Unknown) to return to Nagios for this service
Click Save New Action
Note: To notify the central Nagios server of Alerts, NSCA must be enabled under System: Nagios and Nagios must be
enabled for each applicable host or port
