Console Server & Router User Manual 311
CM4148: 48 RJ-45 RS-232 serial ports *
CM4008: 8 RJ-45 RS-232 serial ports *
SD4002/CM4001: 2 DB-9 RS-232 serial port
SD4001: 1 DB-9 selectable RS-232/422/485 serial port
* models also have 1 DB-9 RS-232 console/ modem serial port
RJ45 ports - 50 to 230,400bps
DB9 port - 2400 to 115,200 bps
ACM5002/3/4(M/W/G): One RJ-45 10/100Base-T Ethernet ports
ACM5004-2, ACM5504-2 and ACM5508-2: Two RJ-45 10/100Base-T
Ethernet ports
IM4208/16/32/48-2: Two RJ-45 10/100Base-T Ethernet ports
IM4216-34: Two RJ-45 10/100Base-T Ethernet ports and 32x RJ-45
10/100Base-T management LAN switched ports
IM4004-5 & ACM5004-5-G-I: One RJ-45 10/100Base-T primary
Ethernet port and 4x RJ-45 10/100Base-T management
LAN switched ports
CM41xx: One RJ-45 10/100Base-T Ethernet ports
