OPI-3601
Specifications Manual
7
6. Optical Specifications
6.1. Basic Optical Specifications
Item Characteristics
Scan method CMOS area sensor (white / black) -
Number of effective pixel (Column) × (Row) 752 × 480 dots
Image capture speed (*1) Frame rate 60 fps
Focal distance Distance from the front edge of scanner 104 mm
Horizontal Approx. 40.6°
View angle
Vertical Approx. 26.4°
Red LED -
Peak wavelength 617 nm
Directivity angle: 2Φ 1/2 (*2) 60°
Illumination light source
(LED × 2)
Maximum radiation output (*3) 15000 mcd
Green LED -
Peak wavelength 528 nm
Aiming light source
Maximum radiation output (*4) 18700 mcd
*1 The fastest seed of image capture
*2 Reference value extracted from the datasheet.
*3, *4 Reference value based on the datasheet (25°C, IF = 140 mA ).
