Opticon OPI-3601 - 3 Basic Specifications

OPI-3601
Specifications Manual
2
3. Basic Specifications
Item Specification Note
CPU
CPU: ARM-926EJ-S
Core: 400 MHz
SDRAM 256 Mbits (2 M × 4 Banks × 32 Bits )
SDCLK: 133 MHz
Control
Section
Flash ROM 16 Mbits (1 M × 16 Bits) Flash Memory
RS-232C 300 bps ~ 115200 bps
Default: 9600bps
USB USB2.0 Full-Speed 12 Mbps (HID/COM)
Interface
Wedge
PS/2 Keyboard (selectable ‘with or without
keyboard connection’)
Scanning method WVGA (0.36 million-pixel) CMOS area sensor
Frame rate: 60 fps
Scanning light source 2 red LEDs
Aiming light source 1 green LED
Effective pixels 0.36 million pixels (H: 752 x V: 480)
Optical Section
View angle
Horizontal: about 40.6°
Vertical: about 26.4°
Symbologies
UPC-A, UPC-A Add-on, UPC-E, UPC-E Add-
on, EAN-13, EAN-13 Add-on, EAN-8, EAN-8
Add-on, JAN-8, JAN-13, Code 39, Tri-Optic,
Codabar (NW-7), Industrial 2 of 5, Interleaved
2 of 5, S-Code, IATA, Code 93, Code 128,
MSI/Plessey, UK/Plessey, TELEPEN, Matrix 2
of 5, Chinese Post Matrix 2 of 5, Code 11,
Korean Postal Authority code, Postal Code
Minimum resolution Code 39 : 0.127 mm
PCS 0.9
Curvature
Radius ≧ 16 mm (12-digit 0.15mm Codabar)
Radius ≧ 20 mm (13-digit UPC)
PCS 0.9
Wide Bar Code
Possible to read: Code 39 with 100 mm width
and resolution 0.2mm (DOF: 135 mm)
Motion tolerance
Possible to read: UPC 100% moving at 2 m/s
(DOF: 100 mm)
Resolution (0.127) 65 ~ 105
Resolution (0.254) 45 ~ 185
Code 39
Resolution (0.508) 50~ 250
Code 128 Resolution (0.2) 65 ~ 150
Supported 1D Symbologies
Depth of field
(mm)
UPC Resolution (0.33) 45 ~ 175
Symbologies
GS1 DataBar, GS1 DataBar Limited, GS1
DataBar Expanded, Composite GS1-DataBar,
Composite GS1-128, Composite EAN,
Composite UPC
GS1 DataBar: formerly
called “RSS”
GS1/Composite
Minimum resolution
GS1 DataBar : 0.169 mm
Composite Code: 0.169 mm
