Opticon OPI-3601 - 10.9. Drop Impact Strength (without packaging); 10.10. Drop Impact Strength (in individual packaging)

OPI-3601
Specifications Manual
26
10.9. Drop Impact Strength (without packaging)
There shall be no sign of malfunction after the following drop test.
Drop test:
Drop the scanner three times (15 times in total), at each 5 face, from a height of
150cm onto a concrete floor as shown below.
Figure 22: Drop Test
10.10. Drop Impact Strength (in individual packaging)
There shall be no sign of malfunction after the following drop test.
Drop test:
Drop an individually packaged scanner 10 times in total, at any of 1 corner, 3 edges,
and 6 faces, from a height of 150 cm onto a concrete floor.
10.11. Electrical Specifications
Withstand Voltage : AC 1500 V / 60 seconds, 10 mA or less
Insulation Resistance : DC 500 V, 2 MΩ or higher
Current Leakage : 250 μA or less / AC 250 V 60 Hz
Power Line Noise Immunity : ±1 kV or lower
Electrostatic Discharge Immunity : No destruction found (±15 kV, air or direct discharge)
: No malfunction found (±10 kV, air or direct discharge)
: ±6 kV (contact, direct or indirect discharge)
*Testing method is compliant with IEC-61000-4-2. (150 pF, 330Ω)
