OPI-3601
Specifications Manual
27
11. Default Setting
11.1. Default Setting Menu Code
The OPI-3601 is set to default settings by reading the following menu label regardless of the
interface types.
Default
@MENU
_
OPTO@ZZ@BAP@ZZ@OTPO
_
UNEM@
11.2. Supported Symbologies
11.2.1. 1D bar codes
Code type Default
Minimum
length
Remarks
UPC ○ -
UPC Add-on 2
UPC Add-on 5
EAN(JAN) ○ -
EAN Add-on 2
EAN Add-on 5
EAN-13 ○
EAN-13 Add-on 2
EAN-13 Add-on 5
EAN-8 ○
EAN-8 Add-on 2
EAN-8 Add-on 5
Code 39 ○ 1 Not transmit ST/SP
Tri-Optic ○ - Not transmit ST/SP
Codabar (NW7) ○ 1 Not transmit ST/SP
Industrial 2of 5 ○ 5
Interleaved 2of 5 ○ 6
S-Code 5
Code 128 ○ 1 GS1 conversion (setting required)
Code 93 ○ 1
IATA ○ 5
MSI/Plessey 3
UK/Plessey 2
Telepen 1
Code 11 1
Matrix 2 of 5 5
Chinese Post Matrix 2 of 5 -
Korean Postal Authority -
Intelligent Mail Barcode -
POSTNET -
JPN (Customer Bar Code) -
