18. Physical Features
18.1. Dimensions
Approx. 56.0 × 108.1 × 148.6 (WDH mm)
18.2. Weight
Approx. 85 g (excluding the cable)
18.3. Mechanical Drawing
Figure 30: Mechanical Drawing
