17. Packaging Specifications
17.1. Individual Packaging (RS-232C/Wedge PS/2)
Put the scanner in a protection poly bag and place it in a box.
Assembled package size: 260 × 115 × 103 (WDH mm)
POLY BAG
OPR32018008C0-00
AC Adaptor
&
Plugs
User's Manual
（5J0062A-C）
Face the optical window down
when you put the scanner in
the box.
Color Tie(Black)
BOX：OPR32018001C0-00
*Put AC-Adaptor & Plugs
RS-232C Only
*①&③ are one product.
AC Adapter(Helms-Man)
：SFP0602000P-PSE
*AC adapter and the plugs are changed
to the new plastic bags.
② OPR-3201
④ Manual
* Put in a box in order of ①～④
① AC Adaptor
② OPR-3201
③ Plugs (4 kinds)
④ User's Manual
① AC ADAPTOR
③Plugs
(4 kinds)
Plastic Bag
OPR32018008C0-00
MADE IN ▲▲▲▲▲
Model No.
MODEL NEME
Spec No.
*ﾊﾞｰｺｰﾄﾞ*
*△△△△△△*
Serial No.
Quantity 1
Item No.
Ｒｏ
*O F 1 O P I3 6 0 1 B *
*- *
OPI-3601-RS232C-BLK+PS
Display for the serial-No.
from『 100001 』to『 199999 』
Same number as the scanner.
Number of six digits.
*Continuous Number
.
BAR CODE LABEL for BOX （3A0002）
【原産国表示】～country of origin～
中国生産（produced in China）＝MADE IN CHINA
日本生産（produced in Japan）＝MADE IN JAPAN
5J0062A
BOX：B88010-24
P
OLY Bag
5
E0021
POLY BAG
5E0021
OPI-3601
Color Tie(BLACK)
5H0001
OPI-3601
Figure 26: Individual Packaging (OF1OPR3601B)
