OPI-3601
Specifications Manual
10
7.1. Barcode Test Sample
1D Bar Codes
<Code 39>
Resolution Symbology PCS Size (mm) No. of Digits
0.127 mm (5 mil) 32 × 10 15
0.20 mm (7.9 mil) 100 × 10 31
0.254 mm (10 mil) 32.5 × 12 7
0.508 mm (20 mil)
Code 39 0.9
36 × 25 4
<Code 128>
Resolution Symbology PCS Size (mm) No. of Digits
0.20 mm (7.9 mil) Code 128 0.9 42 × 10 16
<UPC>
Resolution Symbology PCS Size (mm) No. of Digits
0.330 mm (13 mil) 12-digit UPC 0.9/0.3 31.5 × 25.0 12
<Codabar>
Resolution Symbology PCS Size (mm) No. of Digits
0.15 mm (6 mil) Codabar 0.9 20 × 10 10
GS1 Databar/Composite
<GS1-limited>
Resolution Symbology PCS Size (mm) No. of Digits
0.169 mm (6.7 mil) Limited 0.9 12 × 1.5 14
0.169 mm (6.7 mil) Limited-Composite 0.9 12 × 3.0 26
2D Codes
<PDF417>
Resolution Error Correction PCS Size (mm)
No. of Character
0.169 mm (6.7 mil) 23 × 10
0.254 mm (10 mil)
Level-3 0.9
35 × 15
58
<QR Code: Model-2>
Resolution Error Correction PCS Size (mm)
No. of Character
0.212 mm (8.4 mil) 6 × 6
0.381 mm (15 mil)
M 0.9
11 × 11
44
<Data Matrix>
Resolution Model PCS Size (mm)
No. of Character
0.212 mm (8.4 mil) 5 × 5
0.254 mm (10 mil)
ECC200 0.9
6 × 6
40
* The size is outline dimensions excluding the quiet zones.
