Opticon OPI-3601 - RS-232 C Interface Circuit

OPI-3601
Specifications Manual
17
8.1.3.
RS-232C Interface Circuit
Figure 12: Interface Circuit
Connector : D-Sub 9pin, female
Power supply : EIAJ RC5320A (voltage classification 2) jack
Host
TxD
RxD
RTS
CTS
GND
Jack which supports EIAJ RC5320A
Scanner
ICL3223 equivalents
