OPI-3601
Specifications Manual
24
10.3. Ambient Light Immunity
Scanning performance is guaranteed when the range of illumination on a barcode surface is
between zero and the following values:
Incandescent light : 10,000 lx
Fluorescent light : 10,000 lx
Sunlight : 100,000 lx
<Conditions>
Bar Code Sample : 0.33 mm UPC specified in Chapter 7.1
Distance : 100 mm from the front edge of the camera module
Angle
: α = 0°, β =＋15°, γ = 0°
Curvature : R = ∞
Power Supply Voltage : 5.0 V
Figure 20: Ambient Light Immunity
* Be sure that the direct light or specular reflection from the light source does not enter the light
receiving section of the OPI-3601.
10.4. Dust and Drip Proof
IEC IP42 equivalent
Protection against solid objects: Level 4
Protected against solid objects greater than 1.0 mm
Protection against liquids: Level 2 (JIS IPX2)
Protected against dripping water from the vertical when tilted up to 15°
