OPI-3601
Specifications Manual
3
Item Specification Note
Symbologies
PDF417, MicroPDF417, Codablock F, QR
Code , Micro QR Code, DataMatrix (ECC 0 -
140 / ECC 200), MaxiCode (Modes 2 to 5),
Aztec Code, Chinese Sensible Code
Disable Code 128
when Codablock F is
enabled.
Minimum resolution (mm)
PDF417 : 0.169 mm
QR Code : 0.212 mm
DataMatrix : 0.212 mm
PCS 0.9
Resolution (0.169) 60~ 120
PDF417
Resolution (0.254) 45 ~ 185
Resolution (0.212) 70 ~ 95
QR Code
Resolution (0.381) 35 ~ 165
Supported 2D Symbologies
Depth of field
(mm)
DataMatrix Resolution (0.254) 65 ~ 120
PCS 0.9
Pitch : ±40°
Skew : ±50°
Scan angle
Tilt : ±180°
Common
Minimum PCS 0.3 or more
MRD: 32% or more
Image data format Windows Bitmap, JPEG
Shades of gray 1024, 256, 16, 2
Range of output image Select top/bottom (column) and left/right (row)
Resolution of output image Full,1/2, 1/4
Interface of output image RS-232C, USB-COM
Black spot may appear
on images, however, it
does not affect the
scanning performance..
USB-COM
(full speed)
About 3 sec
Imager
Baud rate
RS-232C
(baud rate: 15.2 kbps)
About 40 sec
Resolution: Full
Range of operating voltage
4.5 ~ 5.5 V: USB
5.4 ~ 6.6 V: RS-232C / Wedge PS/2
(external power supply )
RS-232C / Wedge
(external power
supply): Dedicated AC
adapter 6.0 V ±5%
Reading 300 mA (max)
Power
Current
consumption
(RS-232C)
Standby 75 mA (max)
At 6.0 V, room
temperature/ humidity,
Operating -20~ 50°C
AC adapter: 0 ~ 40°C
Temperature
Storage -20 ~ 60°C
Operating 5 ~ 90% (no condensing, no frost)
Humidity
Storage 5 ~ 90% (no condensing, no frost)
Fluorescent 10,000 lx or less
Ambient light
immunity
Sunlight 100,000 lx or less
UPC 100%
Optical axis angle: 75°
Distance: 100 mm
Vibration
10 Hz ~ 100 Hz, acceleration of 19.6 m/s2,
60 minutes per cycle, repeat once in each X, Y
and Z-direction
Drop
Drop 3 times, at each 5 faces (right, left, front,
back and top), from a height of 150 cm onto a
concrete surface.
* Excluding the part
where the interface
cable is attached
Environmental Specifications
Dust and drip proof IP42
