optris CompactPlus Connect User Manual

CTratio 43-
2.3. Sensor Setup CTratio – Output
2.3.1. Output 1 and 2
The device has two outputs (OUT 1, OUT 2) which can be configured
as desired. The following options are available under Mode:
• Off
• Analog
• Alarm
When Analog is activated, the following signal sources can be selected in the Source field:
▪ TProc
Process temperature
▪ TRatio
Ratio temperature
▪ T1
1 channel temperature
▪ T2
2 channel temperature
▪ Attenuation
Signal attenuation in %
▪ TDet
Temperature of detector
▪ TBox
Box temperature
