CT 57-
3. CT
3.1. Sensor Setup CT – Signal Processing
The button Setup [Menu: Device\ Device Setup] opens a window for the setting of all sensor parameters.
The dialog window is separated into 5 categories:
▪ Signal processing
Setting of Emissivity/ Transmission and Post processing
▪ Output
Setting of Output 1 and Output 2
▪ I/O Pins
Setting the In- and Outputs
▪ Display
Display main value and Backlight/ Alarm setting
▪ Advanced settings
Calibration, USB connection, RS485 Multidrop address
